Visual representation and source code for Generate a component diagram for Supply Chain Management (SCM) System in PlantUML. Use ball-and-socket joints. ProvidedInterface: interfaceAlias — componentAlias (Ensure interface is on the left). RequiredInterface: componentAlias –( interfaceAlias (Ensure interface is on the right and must use the ( to indicate required). Only include component shapes, don’t add shapes like database. Group the components architecturally with packages. left to right direction. Incorporate diagram title with the syntax title Supply Chain Network. Add a brief diagram description that describes the problem or diagram context with a comment block below the title and wrap the comment block using /’ at the start and ‘/’ at the end. Focus on describing the diagram context, do not describe the use of syntaxes Use the theme below: !theme sunlust. Enclose the code in a code block. Wrap the entire code with @startuml and @enduml..
@startuml
!theme sunlust
title Supply Chain Network
/'
This component diagram models the architecture of a Supply Chain Management (SCM) system, illustrating the flow of materials, information, and finances across the supply chain network. The system orchestrates demand forecasting, inventory optimization, order processing, logistics coordination, and supplier collaboration. The diagram captures how different modules interact through well-defined interfaces to ensure seamless visibility from procurement to delivery, addressing challenges such as demand variability, supplier reliability, and distribution efficiency.
'/
left to right direction
skinparam componentStyle uml2
package "Demand & Planning" {
[Demand Forecasting] as DemandForecast
[Supply Planning] as SupplyPlan
}
package "Core Fulfillment" {
[Order Management] as OrderMgmt
[Inventory Manager] as Inventory
[Warehouse Operations] as Warehouse
}
package "Procurement & Logistics" {
[Procurement Service] as Procurement
[Transportation Manager] as Transport
[Supplier Collaboration] as SupplierPortal
}
package "Analytics & Visibility" {
[SCM Analytics] as Analytics
[Track & Trace] as TrackTrace
}
' Provided Interfaces (ball on the left)
iDemandForecast -- DemandForecast
iSupplyPlan -- SupplyPlan
iOrderMgmt -- OrderMgmt
iInventory -- Inventory
iWarehouse -- Warehouse
iProcurement -- Procurement
iTransport -- Transport
iSupplierPortal -- SupplierPortal
iAnalytics -- Analytics
iTrackTrace -- TrackTrace
' Required Interfaces (socket on the right)
DemandForecast --( iSupplyPlan
SupplyPlan --( iInventory
Inventory --( iOrderMgmt
OrderMgmt --( iWarehouse
OrderMgmt --( iTransport
Warehouse --( iProcurement
Procurement --( iSupplierPortal
Transport --( iTrackTrace
Warehouse --( iAnalytics
Transport --( iAnalytics
@enduml
